DC15 5 Series Magnetic Drive Centrifugal Pump

Brand: Flojet

Designed for hot & cold drink vending, water circulation, recirculation & cooling duties in beverage, laboratory, agricultural, print, photographic & industrial processing applications, and other short-time-rated applications.
Features
  • Magnetically coupled, sealless, leak-free design.
  • Pump body orientation easily altered to suit installations.
  • Variable mounting foot positions.
  • Lifts to 16.4 ft (5 m).

Models matching criteria: 2
Magnetic Drive Centrifugal Pump
50+ In Stock
$139.00 CAD
Does not ship to OH, United States
Magnetic Drive Centrifugal Pump
25+ In Stock
$1,461.00 CAD
Does not ship to OH, United States

Specifications

Brand

Dimensions (H x W x D)

  • 3.4 x 5.7 x 2.9 (inches)
  • 86 x 146 x 74 mm

Materials of Construction

  • PP Pump Housing
  • PPS Option Available
  • Stainless Steel Spindle
  • Standard EPDM O-Ring, Optional Nitrile or Silicone or Viton
  • Strontium Ferrite Magnet

Maximum Liquid Temperature

  • -20° to 85° C
  • -4° to 185° F

Maximum System Pressure

  • 1.4 bar
  • 20 psi

Motor Power

  • 25 (W)

Voltage

  • 12 or 24 (Vdc)

Weight

  • 0.7 kg
  • 1.5 lbs
show more
